AD3000 ANNEX A - PARAMETERS LIST
NIDEC ASI S.P.A. – AD3000 COMMUNICATION MANUAL
IMAD30007EN 47
ANNEX A PARAMETERS LIST
This annex describes the necessary parameters to use and set the optional fieldbus boards.
Because fieldbus protocols Modbus TCP, PROFINET IO and EtherNet/IP use the Ethernet network as a physical medium, it is necessary to
configure the Ethernet TCP/IP parameters (ETHERNET – TCP/IP [88.00] family): IP address, Mask and Gateway.
For the PROFIBUS DP, PROFINET IO and EtherNet/IP fieldbus protocols, the parameters are common and are reported in the FIELDBUS [81.00]
family.
In the case of the Modbus TCP protocol, a configuration parameter of the MODBUS [82.00] family enables Modbus TCP; some parameters of
Modbus protocol are not reported in the following table because they refer only to Modbus RTU protocol; for this reason, due to the fact that Modbus
RTU is a standard feature on AD3000 drive, dedicated parameters are reported only in the Programming Manual.
MODBUS
82 - Modbus
Id
Name
Description
Unit
Range
Access
Type
Control
Type
Visibility
Level
Download
82.01
Modbus En
Modbus enable
- Off [0]
- RTU [1]
- TCP [2]
- RTU & TCP [3]
#
Def: Off
Read and
Write
All
2
Yes
82.02
Slav e Address
Slav e address
#
Min: 1
Def: 3
Max : 247
Read and
Write
All
2
Yes
82.05
Timeout
Timeout for alarm 53 (0 = disabled)
s
Min: 0
Def: 3
Max : 250
Read and
Write
All
2
Yes
82.07
Mod Ex change Area
In
Selection of input aux iliary ex change
area (from Modbus to Drive)
- Off [0]
- 1 Data Ex change Area [1]
- 2 Data Ex change Area [2]
#
Def: Off
Read and
Write
All
2
Yes
