ANNEX A - PARAMETERS LIST AD3000
NIDEC ASI S.P.A. – AD3000 COMMUNICATION MANUAL
48 IMAD30007EN
FIELDBUS
81 - FIELDBUS
Id
Name
Description
Unit
Range
Access
Type
Control
type
Visibility
Level
Download
81.01
Fieldbus Sel
Fieldbus selection
- Off [0]
- PROFIBUS DP [1]
- PROFINET IO [2]
- EtherNet/IP [3]
#
Def: Off
Read and
Write
All
2
Yes
81.02
Slav e Address
Slav e address
#
Min: 3
Def: 3
Max : 127
Read and
Write
All
2
Yes
81.03
Timeout
Timeout
s
Min: 0.01
Def: 0.01
Max : 10
Read and
Write
All
2
Yes
81.04
Freeze En
Enable freeze of Speed Ref/Cmd Wd
- Off [0]
- On [1]
#
Def: Off
Read and
Write
All
2
Yes
81.05
Delay Com Restore
Delay w hen communication is
resumed
s
Min: 0
Def: 0
Max : 10
Read and
Write
All
2
Yes
81.20
PPO Ty pe
Selection of PPO type
- PPO1 [1]
- PPO2 [2]
- PPO3 [3]
- PPO4 [4]
- PPO5 [5]
#
Def: PPO5
Read and
Write
All
2
Yes
81.21
IPZ03 Sel
IPZ03 selection
- Off [0]
- Aux Spd Ref [1]
- Add Spd Ref [2]
- Spd Ffw [3]
- Cmd Wd 2 [4]
- Cmd Wd 3 [5]
- Cmd Wd 4 [6]
- Trq Lim Ref Pos [7]
- Trq Lim Ref Neg [8]
- Trq Ref [9]
- Trq Ffw [21]
- PrsPID Ref1 [65]
- PrsPID Fdb1 [66]
- PrsPID Ref2 [67]
- PrsPID Fdb2 [68]
#
Def: Off
Read and
Write
All
2
Yes
81.22
IPZ04 Sel
IPZ04 selection
#
Def: Off
Read and
Write
All
2
Yes
81.23
IPZ05 Sel
IPZ05 selection
#
Def: Off
Read and
Write
All
2
Yes
