AD3000 2 – OPTIONAL BOARDS
NIDEC ASI S.P.A. – AD3000 COMMUNICATION MANUAL
IMAD30007EN 9
2.6 EtherNet/IP communication module
The EtherNet/IP communication module (GB40A-EtherNet/IP expansion board, code 1000256532) provides the EtherNet/IP communication bus; it is
connected to the BASIS control board via J7 and J8.
The physical interfaces are 2 RJ45 connectors to connect Ethernet cables.
Technical data
Operating temperature, -20°C - +50°C
Storage and transport temperature, -20°C - +70°C
LED
Abbreviation
Colour
Function
DL 1
Green
Vcc Power
DL 2
Green
Network status
DL 3
Red
Error
DL 4
Green
Mudule configured
DL 5
Red
Fault
DL 6
Green
Port A Eth Link Activity
100Mb
DL 7
Red
Port A Eth Link Activity
10Mb
DL 8
Green
Port B Eth Link Activity
100Mb
DL 9
Red
Port B Eth Link Activity
10Mb
Two examples in the case of EtherNet/IP:
 DL2 and DL4 On with PLC connected and running
 DL3 Blinking + DL2 off + DL4 blinking network cable disconnected
The GB40A-EtherNet/IP expansion board is an option indicated by the letter E in the 13
th
character of the identification code (see chapter 2 of the User
and Maintenance Manual):
AD3
A
XXX
F
B
N
F
H
E
C
N
00
NN
