3 GENERAL INFORMATION AND RATINGS - 3.1
3
3 GENERAL INFORMATION AND RATINGS
This chapter contains information about the AD700E 700E including how
to identify the drive
3.1 IDENTIFYING THE DRIVE BY MODEL NUMBER
Each drive can be identified by its model number, as shown in the
table below. The model number is on the shipping label and the drive
nameplate. The model number includes the drive and any options.
AD07
-
E
- -
3 2 240 - -3 0 0 0 2 - - -
Product Family
Input Voltage
1 : 110-115 Volt
2 : 200-240 Volt
4 : 380-480 Volt
6 : 500-600 Volt
Input Phases
0 : Non Switched
1 : Switched
EMC Filter
0 : No Internal Filer
1 : Internal EMC Filter
Brake Chopper
1 : No Brake Chopper
4 : Internal Brake
Chopper
Enclosure
2 : IP20
5 : IP55
6 : IP66
= (empty) always
01 = only if 1 Phase
Output model
Motor Amps
Example : 043 = 4,3 A; 105= 10,5 A; X30 = 302A
Family
E = Economy
Frame Size
P = Basic Pump
M = Micro Machine
-
