3.2 DRIVE MODEL NUMBERS
3
3.2 DRIVE MODEL NUMBERS
110 – 115V + / - 10% - 1Phase Input – 3 Phase 230V Output (Voltage Doubler)
Model
kW HP Output Current (A) Frame Size
With Filter Without Filter
N/A AD07-E-1-1-023-1-*00# N/A 0.5 2.3 1
N/A AD07-E-1-1-043-1-*00# N/A 1 4.3 1
N/A AD07-E-2-1-058-1-*01# N/A 1.5 5.8 2
200 – 240V + / - 10% - 1Phase Input – 3 Phase Output
Model
kW HP Output Current (A) Frame Size
With Filter Without Filter
AD07-E-1-2-023-1-*10# AD07-E-1-2-023-1-*00# 0.37 0.5 2.3 1
AD07-E-1-2-043-1-*10# AD07-E-1-2-043-1-*00# 0.75 1 4.3 1
AD07-E-1-2-070-1-*10# AD07-E-1-2-070-1-*00# 1.5 2 7 1
AD07-E-2-2-070-1-*11# AD07-E-2-2-070-1-*01# 1.5 2 7 2
AD07-E-2-2-105-1-*11# AD07-E-2-2-105-1-*01# 2.2 3 10.5 2
N/A AD07-E-3-2-153-1-*01# 4.0 5 15.3 3
200 – 240V + / - 10% - 3Phase Input – 3 Phase Output
Model
kW HP Output Current (A) Frame Size
With Filter Without Filter
N/A AD07-E-1-2-023-3-*00# 0.37 0.5 2.3 1
N/A AD07-E-1-2-043-3-*00# 0.75 1 4.3 1
N/A AD07-E-1-2-070-3-*00# 1.5 2 7 1
AD07-E-2-2-070-3-*11# AD07-E-2-2-070-3-*01# 1.5 2 7 2
AD07-E-2-2-105-3-*11# AD07-E-2-2-105-3-*01# 2.2 3 10.5 2
AD07-E-3-2-180-3-*11# AD07-E-3-2-180-3-*01# 4.0 5 18 3
AD07-E-3-2-240-3-*112 AD07-E-3-2-240-3-*012 5.5 7.5 24 3
AD07-E-4-2-300-3-*112 AD07-E-4-2-300-3-*012 7.5 10 30 4
AD07-E-4-2-460-3-*112 AD07-E-4-2-460-3-*012 11 15 46 4
* NOTE
For IP20 Units, replace ‘#’ with ‘2’
For IP66 Units, replace ‘#’ with ‘6’
For IP66 Non Switched Units, replace ‘*’ with ‘0’
For IP66 Switched Units, replace ‘*’ with ‘1’
