8.5 MACRO FUNCTIONS - FIELDBUS CONTROL MODE (P-12 = 3, 4, 7, 8 OR 9) - 8.6
8
8.5 MACRO FUNCTIONS - FIELDBUS CONTROL MODE (P-12 = 3, 4, 7, 8 OR 9)
8.6 MACRO FUNCTIONS - USER PI CONTROL MODE (P-12 = 5 OR 6)
P-15 DI1 DI2 DI3 / AI2 DI4 / AI1
0 1 0 1 0 1 0 1
0 STOP ENABLE FB REF (Fieldbus Speed Reference, Modbus RTU / CAN / Master-Slave defined by P-12)
1 STOP ENABLE PI Speed Reference
3 STOP ENABLE FB REF P-20 REF E-TRIP OK Analog Input AI1
5 STOP ENABLE FB REF PR REF P-20 P-21 Analog Input AI1
^---------------------------START (P-12 = 3 or 4 Only)--------------------------^
6 STOP ENABLE FB REF AI1 REF E-TRIP OK Analog Input AI1
^-------------START (P-12 = 3 or 4 Only--------------^
7 STOP ENABLE FB REF KPD REF E-TRIP OK Analog Input AI1
^-------------START (P-12 = 3 or 4 Only)------------^
14 STOP ENABLE - - E-TRIP OK Analog Input AI1
15 STOP ENABLE PR REF FB REF Fire Mode OK P-23 P-21
16 STOP ENABLE P-23 REF FB REF Fire Mode OK Analog Input AI1
17 STOP ENABLE FB REF P-23 REF OK Fire Mode Analog Input AI1
2,4,8,9,10,11,12,13 = 0
P-15 DI1 DI2 DI3 / AI2 DI4 / AI1
0 1 0 1 0 1 0 1
0 STOP ENABLE PI REF P-20 REF AI2 AI1
1 STOP ENABLE PI REF AI1 REF AI2 (PI FB) AI1
3, 7 STOP ENABLE PI REF P-20 E-TRIP OK AI1 (PI FB)
4 (NO) START (NC) STOP AI2 (PI FB) AI1
5 (NO) START (NC) STOP PI REF P-20 REF AI1 (PI FB)
6 (NO) START (NC) STOP E-TRIP OK AI1 (PI FB)
8 STOP RUN FWD REV AI2 (PI FB) AI1
14 STOP RUN - - E-TRIP OK AI1 (PI FB)
15 STOP RUN P-23 REF PI REF Fire Mode OK AI1 (PI FB)
16 STOP RUN P-23 REF P-21 REF Fire Mode OK AI1 (PI FB)
17 STOP RUN P-21 REF P-23 REF OK Fire Mode AI1 (PI FB)
2,9,10,11,12,13 = 0
