10.3 ADDITIONAL INFORMATION
FOR UL COMPLIANCE
Input Power Supply Requirements
Supply Voltage 200 – 240 RMS Volts for 230 Volt rated units, + /- 10% variation allowed. 240 Volt RMS Maximum
380 – 480 Volts for 400 Volt rated units, + / - 10% variation allowed, Maximum 500 Volts RMS
Imbalance Maximum 3% voltage variation between phase – phase voltages allowed
All AD700E units have phase imbalance monitoring. A phase imbalance of > 3% will result in the drive tripping.
For input supplies which have supply imbalance greater than 3% (typically the Indian sub- continent & parts of
Asia Pacific including China) NIDEC ASI SPA recommends the installation of input line reactors.
Frequency 50 – 60Hz + / - 5% Variation
Short Circuit Capacity Voltage Rating Min kW (HP) Max kW (HP) Maximum supply
short-circuit current
115V 0.37 (0.5) 1.1 (1.5) 100kA rms (AC)
230V 0.37 (0.5) 11 (15) 100kA rms (AC)
400 / 460V 0.75 (1) 22 (30) 100kA rms (AC)
All the drives in the above table are suitable for use on a circuit capable of delivering not more than the above
specified maximum short-circuit Amperes symmetrical with the specified maximum supply voltage when protected
by Class J fuses.
Mechanical Installation Requirements
All AD700E units are intended for indoor installation within controlled environments which meet the condition limits shown in section 10.1
The drive can be operated within an ambient temperature range as stated in section 10.1
For IP20 units, installation is required in a pollution degree 1 environment
For IP66 (Nema 4X) units, installation in a pollution degree 2 environment is permissible
Frame size 4 drives must be mounted in an enclosure in a manner that ensures the drive is protected from 12.7mm (1/2 inch) of deformation of the
enclosure if the enclosure impacted.
10.3 ADDITIONAL INFORMATION FOR UL COMPLIANCE
10
NOTE: Single Phase Operation of Three Phase Drives
All drive models intended for operation from three phase mains power
supply (e.g. model codes AD07-E-x-x-xxx-3-xxxx) may be operated from
a single phase supply at up to 50% of maximum rated output current
capacity.
In this case, the AC power supply should be connected to L1 (L) and L2 (N)
power connection terminals only.
