1.1 ELECTROMAGNETIC COMPATIBILITY
1.1 ELECTROMAGNETIC COMPATIBILITY
All AD700E drives are designed with high standards of EMC in mind. All
versions suitable for operation on Single Phase 230 volt and Three Phase
400 volt supplies and intended for use within the European Union can be
ordered with an internal EMC filter. This EMC filter is designed to reduce
the conducted emissions back into the supply via the power cables for
compliance with the above harmonised European standards.
It is the responsibility of the installer to ensure that the equipment or
system into which the product is incorporated complies with the EMC
legislation of the country of use. Within the European Union, equipment
into which this product is incorporated must comply with the EMC
Directive 2004/108/EC. When using an AD700E with an internal or
optional external filter, compliance with the following EMC Categories, as
defined by EN61800-3:2004 can be achieved:
All rights reserved. No part of this User Guide may be reproduced
or transmitted in any form or by any means, electrical or mechanical
including photocopying, recording or by any information storage or
retrieval system without permission in writing from the publisher.
For the warranty period and the conditions, refer to the Order Acceptance.
The manufacturer accepts no liability for any damage caused during or
resulting from transport, receipt of delivery, installation or commissioning.
The manufacturer also accepts no liability for damage or consequences
resulting from inappropriate, negligent or incorrect installation,
incorrect adjustment of the operating parameters of the drive, incorrect
matching of the drive to the motor, incorrect installation, unacceptable
dust, moisture, corrosive substances, excessive vibration or ambient
temperatures outside of the design specification.
The local distributor may offer different terms and conditions at their
discretion, and in all cases concerning warranty, the local distributor should
be contacted first.
This user guide is the “original instructions” document.
All non-English versions are translations of the “original
instructions”.
The contents of this User Guide are believed to be correct at the time
of printing. In the interest of a commitment to a policy of continuous
improvement, the manufacturer reserves the right to change the
specification of the product or its performance or the contents of the User
Guide without notice.
This User Guide is for use with version 3.00 Firmware.
User Guide Revision 1.01
NIDEC adopts a policy of continuous improvement and whilst every effort
has been made to provide accurate and up to date information, the
information contained in this User Guide should be used for guidance
purposes only and does not form the part of any contract.
Drive Type / Rating
EMC Category
Cat C1 Cat C2 Cat C3
1 Phase, 230 Volt Input
AD07-E-X-2-XXX-1-XXXX
No additional filtering required
Use shielded motor cable
3 Phase, 400 Volt Input
AD07-E-X-4-XXX-3-XXXX
Use External Filter No additional filtering required
Use Shielded Motor Cable
Note
Compliance with EMC standards is dependent on a number of factors including the environment in which the drive is installed, motor
switching frequency, motor, cable lengths and installation methods adopted.
For shielded motor cable lengths greater than 100m and up to 200m, an output dv / dt filter must be used (please refer to the Nidec Stock
Drives Catalogue for further details).
Compliance with EMC directives is achieved with the factory default parameter settings
