8 ANALOG AND DIGITAL INPUT MACRO
CONFIGURATIONS
8.1 OVERVIEW
AD700E uses a Macro approach to simplify the configuration of the
Analog and Digital Inputs. There are two key parameters which determine
the input functions and drive behaviour:
• P-12 – Selects the main drive control source and determines how the
output frequency of the drive is primarily controlled.
• P-15 – Assigns the Macro function to the analog and digital inputs.
Additional parameters can then be used to further adapt the settings, e.g.
• P-16 – Used to select the format of the analog signal to be connected to
analog input 1, e.g. 0 – 10 Volt, 4 – 20mA
• P-30 – Determines whether the drive should automatically start
following a power on if the Enable Input is present
• P-31 – When Keypad Mode is selected, determines at what output
frequency / speed the drive should start following the enable command,
and also whether the keypad start key must be pressed or if the Enable
input alone should start the drive.
• P-47 – Used to select the format of the analog signal to be connected to
analog input 2, e.g. 0 – 10 Volt, 4 – 20mA
The diagrams below provide an overview of the functions of each terminal
macro function, and a simplified connection diagram for each.
8.2 MACRO FUNCTIONS GUIDE KEY
STOP / RUN Latched input, Close to Run, Open to Stop
Forward Rotation/ Selects the direction of motor operation
Reverse Rotation
AI1 REF Analog Input 1 is the selected speed reference
P-xx REF Speed setpoint from the selected preset speed
PR-REF Preset speeds P-20 – P-23 are used for the speed
reference, selected according to other digital
input status
^-FAST STOP (P-24)-^ When both inputs are active simultaneously,
the drive stops using Fast Stop Ramp Time P-24
E-TRIP External Trip input, which must be Normally Closed.
When the input opens, the drive trips showing
E-tr,P or Ptc-th depending on P-47 setting
(NO) Normally Open Contact, Momentarily Close to Start
(NC) Normally Closed Contact, momentary Open to Stop
Fire Mode Activates Fire Mode, see section 8.7 Fire Mode
ENABLE Hardware Enable Input. In Keypad Mode, P-31
determines whether the drive immediately starts,
or the keypad start key must be pressed. In other
modes, this input must be present before the start
signal via the fieldbus interface
INC SPD Normally Open, Close the input to Increase
the motor speed
DEC SPD Normally Open, Close input to Decrease motor speed
KPD REF Keypad Speed Reference selected
FB REF Selected speed reference from Fieldbus
(Modbus RTU / CAN Open / Master depending
on P-12 setting)
8 ANALOG AND DIGITAL INPUT MACRO CONFIGURATIONS
8
To Next Page
