8.3 MACRO FUNCTIONS – TERMINAL MODE (P-12 = 0) - 8.4
8
8.4 MACRO FUNCTIONS - KEYPAD MODE (P-12 = 1 OR 2)
P-15 DI1 DI2 DI3 / AI2 DI4 / AI1
0 1 0 1 0 1 0 1
0 STOP ENABLE - INC SPD - DEC SPD FWD REV
^--------------------START-------------------^
1 STOP ENABLE PI Speed Reference
2 STOP ENABLE - INC SPD - DEC SPD KPD REF P-20 REF
^--------------------START-------------------^
3 STOP ENABLE - INC SPD E-TRIP OK - DEC SPD
^--------------------------------------------START-------------------------------------------------^
4 STOP ENABLE - INC SPD KPD REF AI1 REF AI1
6 STOP ENABLE FWD REV E-TRIP OK KPD REF P-20 REF
7 STOP RUN FWD STOP RUN REV E-TRIP OK KPD REF P-20 REF
^--------------------FAST STOP (P-24)-------------------^
14 STOP RUN - - E-TRIP OK - -
15 STOP RUN PR REF KPD REF Fire Mode OK P-23 P-21
16 STOP RUN P-23 REF KPD REF Fire Mode OK FWD REV
17 STOP RUN KPD REF P-23 REF OK Fire Mode FWD REV
5,8,9,10,11,12, 13 = 0
2/2
P-15 DI1 DI2 DI3 / AI2 DI4 / AI1
0 1 0 1 0 1 0 1
12 STOP RUN FAST STOP
(P-24)
OK AI1 REF P-20 REF Analog Input AI1
13 (NO) START FWD STOP (NC) (NO) START REV KPD REF P-20 REF
^-----------------------------FAST STOP (P-24)------------------------------------------^
14 STOP RUN DI2 E-TRIP OK DI2 DI4 PR
0 0 P-20
1 0 P-21
0 1 P-22
1 1 P-23
15 STOP RUN P-23 REF AI1 Fire Mode OK Analog Input AI1
16 STOP RUN P-23 REF P-21 REF Fire Mode OK FWD REV
17 STOP RUN DI2 E-TRIP OK Fire Mode DI2 DI4 PR
0 0 P-20
1 0 P-21
0 1 P-22
1 1 P-23
