Electrical Installation Requirements
Incoming power supply connection must be according to sections 5.4 and 5.5
Suitable Power and motor cables should be selected according to the data shown in section 10.2 and the National Electrical Code or other applicable
local codes.
Motor Cable 75°C Copper must be used
Power cable connections and tightening torques are shown in sections 4.3 and 4.5
Integral Solid Sate short circuit protection does not provide branch circuit protection. Branch circuit protection must be provided in accordance with the
national electrical code and any additional local codes. Ratings are shown in section 10.2
Transient surge suppression must be installed on the line side of this equipment and shall be rated 480Volt (phase to ground), 480 Volt (phase to phase),
suitable for over voltage category III and shall provide protection for a rated impulse withstand voltage peak of 4kV.
UL Listed ring terminals / lugs must be used for all bus bar and grounding connections
General Requirements
AD700E provides motor overload protection in accordance with the National Electrical Code (US).
• Where a motor thermistor is not fitted, or not utilised, Thermal Overload Memory Retention must be enabled by setting P-60 = 1
• Where a motor thermistor is fitted and connected to the drive, connection must be carried out according to the information shown in section 5.7.2
10.3 ADDITIONAL INFORMATION FOR UL COMPLIANCE
