7.2 EXTENDED PARAMETERS
Par Description Minimum Maximum Default Units
P-47 Analog Input 2 Signal Format - - - U0-10
U 0-10 = 0 to 10 Volt Signal
A 0-20 = 0 to 20mA Signal
t 4-20 = 4 to 20mA Signal, the AD700E will trip and show the fault code 4-20f if the signal level falls below 3mA
r 4-20 = 4 to 20mA Signal, the AD700E will ramp to stop if the signal level falls below 3mA
t 20-4 = 20 to 4mA Signal, the AD700E will trip and show the fault code 4-20F if the signal level falls below 3mA
r 20-4 = 20 to 4mA Signal, the AD700E will ramp to stop if the signal level falls below 3mA
Ptc-th = Use for motor thermistor measurement, valid with any setting of P-15 that has Input 3 as E-Trip. Trip level : 3kΩ, reset 1kΩ
P-48 Standby Mode Timer 0.0 25.0 0.0 s
When standby mode is enabled by setting P-48 > 0.0, the drive will enter standby following a period of operating at minimum speed (P-02) for
the time set in P-48. When in Standby Mode, the drive display shows Stndby, and the output to the motor is disabled.
P-49 PI Control Wake Up Error Level 0.0 100.0 5.0 %
When the drive is operating in PI Control Mode (P-12 = 5 or 6), and Standby Mode is enabled (P-48 > 0.0), P-49 can be used to define the PI
Error Level (E.g. difference between the setpoint and feedback) required before the drive restarts after entering Standby Mode. This allows the
drive to ignore small feedback errors and remain in Standby mode until the feedback drops sufficiently.
P-50 User Output Relay Hysteresis 0.0 100.0 0.0 %
Sets the hysteresis level for P-19 to prevent the output relay chattering when close to the threshold.
