2 IMPORTANT SAFETY INFORMATION
2
Within the European Union, all machinery in which this product is used must comply with Directive 2006/42/EC, Safety of Machinery. In particular,
the machine manufacturer is responsible for providing a main switch and ensuring the electrical equipment complies with EN60204-1.
The level of integrity offered by the AD700E control input functions – for example stop/start, forward/reverse and maximum speed is not sufficient
for use in safety-critical applications without independent channels of protection. All applications where malfunction could cause injury or loss of
life must be subject to a risk assessment and further protection provided where needed.
The driven motor can start at power up if the enable input signal is present.
The STOP function does not remove potentially lethal high voltages. ISOLATE the drive and wait 10 minutes before starting any work on it. Never
carry out any work on the Drive, Motor or Motor cable whilst the input power is still applied.
The AD700E can be programmed to operate the driven motor at speeds above or below the speed achieved when connecting the motor directly
to the mains supply. Obtain confirmation from the manufacturers of the motor and the driven machine about suitability for operation over the
intended speed range prior to machine start up.
Do not activate the automatic fault reset function on any systems whereby this may cause a potentially dangerous situation.
IP20/NEMA 2 drives must be installed in a pollution degree 2 environment, mounted in a cabinet with IP54/NEMA 3 or better.
AD700E are intended for indoor use only.
When mounting the drive, ensure that sufficient cooling is provided. Do not carry out drilling operations with the drive in place, dust and swarf
from drilling may lead to damage.
The entry of conductive or flammable foreign bodies should be prevented. Flammable material should not be placed close to the drive
Relative humidity must be less than 95% (non-condensing).
Ensure that the supply voltage, frequency and no. of phases (1 or 3 phase) correspond to the rating of the AD700E as delivered.
Never connect the mains power supply to the Output terminals U, V, W.
Do not install any type of automatic switchgear between the drive and the motor
Wherever control cabling is close to power cabling, maintain a minimum separation of 100 mm and arrange crossings at 90 degrees
Ensure that all terminals are tightened to the appropriate torque setting
Do not attempt to carry out any repair of the AD700E. In the case of suspected fault or malfunction, contact your local Nidec
representative www.nidec-industrial.com for further assistance.
