7.2.2 Menu 2 - Reference & ramps
Parameter
Range Default
P2.01 Minimum Frequency Limit 0.0 to 300.0 Hz 0.0 Hz
P2.02 Maximum Frequency Limit 0.0 to 300.0 Hz
50Hz: 50.0 Hz
60Hz: 60.0 Hz
P2.03 Frequency Reference Configuration
Custom (0), Local/Remote (1), Voltage/Presets (2), Current/Presets (3),
Presets (4), Keypad (5), Terminal Up/Down (6), Frequency Input (7),
PID Voltage Ref. (8), PID + Feed Forward (9)
Local/Remote (1)
P2.04 Stopping Mode Selector
Coast (0), Ramp (1), Ramp & DC Brake (2), Brake + StopDetect (3),
Timed DC Brake (4) Distance (5)
Ramp (1)
P2.05 S-Ramp Percentage 0.0 to 50.0 % 0.0 %
P2.06 Acceleration Rate 1 0.0 to 1999.9 s 5.0 s
P2.07 Deceleration Rate 1 0.0 to 1999.9 s 10.0 s
P2.08 Acceleration Rate 2 0.0 to 1999.9 s 5.0 s
P2.09 Deceleration Rate 2 0.0 to 1999.9 s 10.0 s
P2.10 Ramp Rate Selector DI Select (0), Ramp Rates 1 (1), Ramp Rates 2 (2) DI Select (0)
P2.11 Deceleration Ramp Type Fast (0), Standard Ramp (1), Standard Ramp + Motor Loss (2) Standard Ramp (1)
P2.12 Standard Ramp Voltage 0 to DC Bus Voltage (Max) V Rating Dependent
P2.13 Jog Frequency ± Maximum Frequency Reference (P2.02) Hz 1.5 Hz
P2.14 Up/Down Percent Configuration
Reset (0), Last (1), Preset 1 (2), Keypad and Reset (3), Keypad and Last (4),
Keypad and Preset 1 (5)
Reset (0)
P2.15 Up/Down Percentage Time to Max 0 to 250 s 20 s
P2.16 Preset Frequency 1
± Maximum Frequency Reference (P2.02) Hz
5.0 Hz
P2.17 Preset Frequency 2 10.0 Hz
P2.18 Preset Frequency 3 25.0 Hz
P2.19 Preset Frequency 4 50.0 Hz
P2.20 Frequency Reference 1 to 4 Selector
Binary (0), Freq. Reference 1 (1), Freq. Reference 2 (2), Freq. Reference 3 (3),
Freq. Reference 4 (4)
Binary (0)
P2.21 Frequency Reference 1 Selector
None (0), Preset 1 (1), Preset 2 (2), Preset 3 (3), Preset 4 (4), T2 Analog 1 % (5),
T4 Analog 2 % (6), T15 Frequency % (7), Up/Down % (8), PID Percent (9)
T2 Analog 1 % (5)
P2.22 Frequency Reference 2 Selector T4 Analog 2 % (6)
P2.23 Frequency Reference 3 Selector None (0)
P2.24 Frequency Reference 4 Selector None (0)
P2.25 Skip Frequency 0.0 to Maximum Frequency Reference (P2.02) Hz 0.0 Hz
P2.26 Skip Frequency Band 0.0 to 25.0 Hz 0.5 Hz
P2.27 Fire Mode Reference ± Maximum Frequency Limit (P2.02) Hz 0.0 Hz
