88 Digistart D3: User Guide
Issue: G
4. Press M. The Digistart D3 simulates starting. The Run LED flashes.
Run Simulation
Starting X:XXs
to Continue
5. Press M. The Digistart D3 simulates running. The Run LED stays on
without flashing and the bypass contactor relay closes.
Run Simulation
Running
Apply Stop Signal
6. Press STOP or activate the stop input. The Digistart D3 simulates
stopping. The Run LED flashes and the bypass contactor relay opens.
Run Simulation
Stopping X:XXs
to Continue
7. Press M. The Ready LED flashes and the main contactor relay opens.
Run Simulation
Stopped
to Continue
8. Press M to return to the commissioning menu.
Testing the Installation
The Digistart D3 can be connected to a small motor for testing. During this test, the soft starter's control input and
relay output protection settings can be tested. This test mode is not suitable for testing soft starting or soft stopping
performance.
The FLC of the test motor must be at least 2% of the soft starter's minimum FLC (see Minimum and Maximum
Current Settings on page 13).
NOTE
When testing the soft starter with a small motor, set Pr 1A Motor Full Load Current to the minimum
allowable value.
Output signal simulations
The following outputs are available to simulate:
• Programmable relay A
• Programmable relay B
• Programmable relay C
• Run relay
• Low Current Flag
• High Current Flag
• Motor Temperature Flag
• Analog output A
• Analog output B
NOTE
To test operation of the flags (motor temperature and low/high current), set an output relay to the
appropriate function and monitor the relay's behaviour.
To use the signal simulation:
1. Open the Menu and select Simulation.
2. Use the and buttons to select a function to simulate, then press
M
.
3. Use the and buttons to turn the signal on and off.
To confirm correct operation, monitor the state of the output.
Prog Relay A
Off
On
4. Press to return to the simulation list.
