Digistart D3: User Guide 89
Issue: G
The analog output simulation uses the and buttons to change the current
at the analog output terminals.
Analog Output A
0%
4.0mA
Attach a current measuring device to the analog output terminals. Use the or button to adjust the percentage
value on the display. The current measuring device should indicate the same level of current as shown on the
display.
If the input/output expansion card is fitted, the simulation can also be used to test the operation of Relays D, E, F and
Analog Output B.
8.9.3 I/O state
Analog I/O State
This screen shows the current status of the Analog I/O
Analog I/O State
Input: - - - - %
Output A: 04.0mA
This screen will also show Analog Output B if the expansion card is fitted.
Digital I/O State
This screen shows the current status of the digital inputs and outputs.
Digital I/O State
Inputs: 0110000
Outputs: 0000100
The top line of the screen shows the start, stop, reset and programmable inputs (A and B, then inputs on the I/O
expansion card (if fitted).
The bottom line of the screen shows programmable output A, the fixed Run output, programmable outputs B and C,
then the outputs on the expansion card (if fitted).
Temperature Sensors State
This screen shows the state of the motor thermistors and RTD/PT100s.
S = Short
H = Hot
C = Cold
O = Open
Temp Sensors State
Thermistor: 0
RTD/PT100s:OOOOOOO
S = Shrt H=Hot C=Cld O=Opn
RTD/PT100s B ~ G are only available if the RTD/PT100 and Ground Fault expansion card is fitted.
8.9.4 Logs Menu
The Logs Menu provides information on events, trips and starter performance.
To open the Logs Menu, press the M button, then scroll to Logs and press M again.
Trip Log
The Trip Log stores details of the eight most recent trips, including the date and time the trip happened. Trip 1 is the
most recent and trip 8 is the oldest stored trip.
To open the Trip Log:
1. Open the Logs Menu.
2. Scroll to Trip Log and press M.
3. Use the and buttons to select a trip to view, and press M to display details.
To close the log and return to the main display, press
repeatedly.
Event Log
The Event Log stores time-stamped details of the starter's 99 most recent events (actions, warnings and trips),
including the date and time of the event. Event 1 is the most recent and event 99 is the oldest stored event.
To open the Event Log:
1. Open the Logs Menu.
2. Scroll to Event Log and press M.
3. Use the and buttons to select an event to view, and press M to display details.
To close the log and return to the main display, press
repeatedly.
