Nidec Digitax HD M751 Base - Page 37

Safety information Product information Mechanical installation Electrical installation Multi axis system design Technical data
Digitax HD M75X Series Installation and Technical Guide 37
Issue Number: 5
Figure 3-24 External EMC filter dimensions (4200-5033)
Table 3-4 External EMC filter dimensions (4200-5033)
W
C
H
A
D
Y
V
B
Part number ABCDHWVY
4200-5033
180 mm
(7.09 in)
115 mm
(4.53 in)
100 mm
(3.94 in)
60 mm
(2.36 in)
230 mm
(9.06 in)
115 mm
(4.53 in)
M6
6.5 mm
(0.256 in)
