88 SM-Applications Modules & Motion Processors User Guide

Issue Number: 4

GETPARATTR

This is used to get parameter attributes such as maximum and minimum values, read-

only flag, etc.

CModeXfer

This allows the user to change the drive mode without any fitted option modules getting

a hard reset. It allows for a smoother drive mode change. While the drive mode change

occurs fieldbuses will not be able to write to parameters and this is handled at system

level. They will NOT get a ‘write to parameter failed’ message during this period.

RtuReadRegs

RtuReadParas

RtuReadInputRegs

RtuPresetRegs

RtuPresetParas

RtuMasterReply

RtuMasterStatus

These commands are implemented to allow the user to utilise the SM-Applications,

SM-Applications Plus and Digitax ST Plus modules Modbus RTU master functionality.

Refer to the on-line help for further details.

PFIXREAD6/PFIXWRITE6

These blocks provide reading and writing of drive parameters in a fixed precision of 6

decimal places.

SETUSERID

This command is used to set the User ID Pr 81.49.

ANSIREPLY

This command existed in the UD70, however the syntax has changed for the Second

Processor.

It is a EIA-RS485 port function which is used in conjunction with the ANSIREAD and

ANSIWRITE functions.

(Max%, Min%, Flags%) = GETPARATTR(Menu%, Par%)

Menus 15 to 20 will not be defaulted when using this command.

SETUSERID(101) // set #81.49 to 101.

(Status%, Reply%) = ANSIREPLY()

NOTE
