68 SM-Applications Modules & Motion Processors User Guide
Issue Number: 4
5.11 Menu 20 - Application Menu
This menu, like menus 18 and 19, contains parameters that do not affect the operation
of the drive and therefore can be used for general purpose.
Pr
81.21 is set, this menu will be saved and restored by the Second Processor..
On the drive display/keypad if the value exceeds the maximum that can be displayed
(9,999,999), “------” will be shown. It is not possible to enter values larger than the
maximum display value on the keypad.
Menu 97 - Internal Motion Processor Parameters
Pr 97.00 to Pr 97.99 are 32 bit parameters and are reserved for the internal motion
processor. They can be read and written to from the user program, but are not
accessible by the LCD or LED keypads.
This menu is NOT saved in the drive’s non-volatile memory. Instead it can be stored in
the Second Processor flash memory upon request. If more than one Second Processor
is fitted, only one should be configured to store and restore this menu for obvious
reasons.
Pr 20.01-
Pr 20.20
Integer, read-write
Access RW Range Signed 16-bit
Default 0 Update Rate N/A
Apps Apps Lite Apps Plus Lite V2 ST Plus ST Indexer
Pr 20.21
Pr 20.40
Long integer, read-write
Access RW Range Signed 32-bit
Default 0 Update Rate N/A
Apps Apps Lite Apps Plus Lite V2 ST Plus ST Indexer
Apps Apps Lite Apps Plus Lite V2 ST Plus ST Indexer
