SM-Applications Modules & Motion Processors User Guide 61
Issue Number: 4
Safety
Information
Introduction Installation
Getting
Started
Parameters
DPL
Programming
Communications
Freeze and
Marker
CTSync
Inter-option
Synchronization
Diagnostics
Migration
Guide
Quick
Reference
Index
5.9 Menu 91 - Fast Access Parameters
The parameters in this menu are Second Processor virtual parameters which provide a
faster update rate or enhanced resolution than drive parameters.
This parameter enables the short-cut parameters detailed later in this section. You must
set the appropriate bit in this parameter. See the following table.
Sets the speed reference in units of
0.001RPM. This value is mirrored in drive Pr 01.21
(preset speed 1), therefore in order to control the drive speed with this parameter
ensure preset speed 1 is selected on the drive (Pr
01.14=3, Pr 01.15=1).
Ensure bit 0 of Pr
91.01 is set and the full-scale speed in Pr 91.05 is set accordingly
when using this parameter
Controls the hard-speed reference on the drive in units of
0.001RPM.
Ensure bit 1 of Pr
91.01 is set and the full-scale speed in Pr 91.05 is set accordingly
when using this parameter. Note that this parameter is valid only in Closed Loop Vector
and Servo modes only.
Pr 91.01 Short-cut enable
Access RW Range Unsigned 8-bit
Default 0 Update Rate Immediate
Bit Function
Related
Parameter
0 Speed reference shortcut enable Pr 91.02
1 Hard-speed reference shortcut enable Pr 91.03
2 Torque reference shortcut enable Pr 91.04
3 Analogue Output 1 Pr 91.11
4 Analogue Output 2 Pr 91.12
5 Reserved -
6 Reserved -
7 Reserved -
Apps Apps Lite Apps Plus Lite V2 ST Plus ST Indexer
Pr 91.02 Speed set-point (Pr 01.21)
Access RW Range Signed 32-bit
Default N/A Update Rate 250µs
Apps Apps Lite Apps Plus Lite V2 ST Plus ST Indexer
Pr 91.03 Hard-speed reference (Pr 03.22)
Access RW Range Signed 32-bit
Default N/A Update Rate 250µs
Apps Apps Lite Apps Plus Lite V2 ST Plus ST Indexer
