Nidec SM-Applications Series - 13 Quick Reference

124 SM-Applications Modules & Motion Processors User Guide
Issue Number: 4
13 Quick Reference
Refer to section 5 Parameters on page 28 for full details of these parameters.
Table 13-1 Setup Parameters
Parameter Description Cross Ref Range Default
Pr 81.01 Module option code Section 5.3.1 on page 29 0-499 N/A
Pr
81.02 Module firmware version Section 5.3.1 on page 29 0-99.99 N/A
Pr
81.03
DPL program status
Section 5.3.1 on page 29 0-3 N/A
Pr
81.04
Available system resource %
Section 5.3.1 on page 29 0-100% N/A
Pr
81.05
EIA-RS485 address
Section 5.3.1 on page 30 0-255 11
Pr
81.06
EIA-RS485 Mode
Section 5.3.1 on page 30 0-255 1
Pr
81.07
EIA-RS485 Baud rate
Section 5.3.1 on page 31 0-9 4
Pr
81.08
EIA-RS485 Turn-around delay
Section 5.3.1 on page 32 0-255ms 2ms
Pr
81.09
EIA-RS485 Tx Enable Delay
Section 5.3.1 on page 32 0-1ms 0ms
Pr
81.10
DPL print routing
Section 5.3.1 on page 32 0-1 0
Pr
81.11
Clock tick time (ms)
Section 5.3.1 on page 32 0-200ms 0
Pr
81.12
POS task schedule rate
Section 5.3.1 on page 33 0-6 0
Pr
81.13
Enable autorun
Section 5.3.1 on page 33 0-1 1
Pr
81.14
Global run-time trip enable
Section 5.3.1 on page 33 0-1 0
Pr
81.15
Disable Reset on Trip Cleared
Section 5.3.1 on page 33 0-1 0
Pr
81.16
Encoder Data Update Rate
Section 5.3.1 on page 34 0-3 0
Pr
81.17
Enable parameter over-range trips
Section 5.3.1 on page 34 0-1 0
Pr
81.18
Watchdog enable
Section 5.3.1 on page 34 0-1 0
Pr
81.19
Save request
Section 5.3.1 on page 35 0-1 0
Pr
81.20
Save on ‘UU’ trip
Section 5.3.1 on page 35 0-1 0
Pr
81.21
Include menu 20 for save/restore
Section 5.3.1 on page 35 0-1 0
Pr
81.22
CTNet token ring ID
Section 5.3.1 on page 36 0-255 0
Pr
81.23
CTNet node address
Section 5.3.1 on page 36 0-255 0
Pr
81.24
CTNet baud-rate
Section 5.3.1 on page 36 0-3 1
Pr
81.25
CTNet sync setup (SSFF)
Section 5.3.1 on page 36 0-9999 0
Pr
81.26
CTNet Easy Mode 1 destination node
(NNNSS)
Section 5.3.1 on page 37 0-25503 0
Pr
81.27
CTNet Easy Mode 1 source parameter
(MMPP)
Section 5.3.1 on page 37 0-9999 0
Pr 81.28
CTNet Easy Mode 2 destination node
(NNNSS)
Section 5.3.1 on page 37 0-25503 0
Pr 81.29
CTNet Easy Mode 2 source parameter
(MMPP)
Section 5.3.1 on page 37 0-9999 0
Pr 81.30
CTNet Easy Mode 3 destination node
(NNNSS)
Section 5.3.1 on page 37 0-25503 0
Pr 81.31
CTNet Easy Mode 3 source parameter
(MMPP)
Section 5.3.1 on page 37 0-9999 0
