Nidec SPDM CONTROL BOX User Manual

1 – TECHNICAL DATA SPDM CONTROL PANEL
NIDEC ASI S.P.A. – SPDM CONTROL PANEL USER MANUAL
12 IMSPDCB2EN
1.2 Plate
The following figure shows an example of a plate that is on SPDM CONTROL PANEL:
Serial Number
Power supply Voltage
SPDM CONTROL PANEL
Identification
Product test date
1.3 Technical data
AC main voltage Synchronism 400 V +10%, -20% 3ph 50÷60 Hz 30 VA
Control 110÷230 V 2ph 50÷60 Hz
Synchronization frequency range 45 - 65 Hz
Automatic matching to the frequency value and to the phase cyclic rotation.
Speed static precision : with tacho generator feedback 0.1 %
with encoder (pulse generator) feedback 0.01 %
with armature voltage feedback 2 %
at contemporary variations of:
AC main voltage ±10 %
load current 0 -100 %
operating temperature 10° C
Speed resolution : with encoder 0.005%
Dead zone on bridge reversing: min. 3.3 ms
Nidec ASI SpA
Montebello vicentino ITALY
TYPE
N°
DATE
POWER
SUPPLY
CODE

Nidec SPDM CONTROL BOX Specifications

General

Brand	Nidec
Model	SPDM CONTROL BOX
Category	Controller
Language	English
