SPDM CONTROL PANEL 1 – TECHNICAL DATA
NIDEC ASI S.P.A. – SPDM CONTROL PANEL USER MANUAL
IMSPDCB2EN 13
Resolution of analog inputs and outputs available for user:
Signal I/O Terminals Sampling rate Resolution
AnIn1 Differential Input ME-34(-)/35(+)
10kHz 11 bit + sign
AnIn2 Differential Input ME-36(-)/37(+)
AnIn3 Differential Input ME-38(-)/39(+)
AnIn4 Differential Input ME-40(-)/41(+)
AnOut1 Output ME-42 / gnd ME-21
AnOut2 Output ME-43 / gnd ME-21
AnOut3 Output ME-44 / gnd ME-24
AnOut4 Output ME-45 / gnd ME-24
Max current regulator bandwidth: 360 rad/s
Max speed regulator bandwidth: 60 rad/s
Protection grade: IP20
1.4 Admissible environmental conditions
Operation: Operate drive installed in a permanent place and protected from adverse weather in accordance with IEC 721-3-3.
Ambient Temperature
0 to 40 °C.(32 to 104 °F)
Relative Humidity 5 to 95% without condensation
Contamination Levels
(Boards with coating) — Chemical gases: IEC 721-3-3, Class 3C2
Solid particles: IEC 721-3-3, Class 3S2
Altitude
Up to 1000 m (3280 ft) above sea level. Over 1000 m (3280 ft) above sea level, the heat dissipation
could require a forced ventilation. Maximum height 3000 m (9840 ft)
Vibrations
Max 0.3 mm/ 0.012in. (from 2 to 9 Hz), max 1 m/s2 3.28ft1s2 (from 9 to 200 Hz) sinusoidal (Class 3 M1)
Environmental
considerations
 Avoid exposure to corrosive gases — including hydrogen sulfide
 Avoid exposure to strong magnetic fields, nuclear radiation and high levels of RFI from
communication transmitters
Storage
Storage: Store in protective packing and in protected environment in accordance with IEC 721-3-1.
Ambient temperature -25°C to +70°C ( -13°F to +158°F)
Relative Humidity Max 95% at 40 °C. - Max 95% at 104 °F.
Atmospheric pressure from 70 to 106 kPa
Vibrations
Max 1.5 mm / 0.06in. (from 2 to 9 Hz), max 5 m/s2 / 16.4 ft/s2 (from 9 to 200 Hz) sinusoidal (class 1 M3)
Shock max 100 m/s2 ( 330fUs2 ), 11 ms ( 36fts ) (class 1 M3).
Contamination Levels
Boards with coating
—
Chemical gases: IEC 721
-
3
-
1, Class 1C2
Solid particles: IEC 721-3-1, Class 1S3
Environmental Considerations
 Avoid exposure to corrosive gases — including hydrogen sulfide
 Avoid exposure to strong magnetic fields, nuclear radiation and high levels of RFI from communication
transmitters
