3 – SYSTEM2 BOARD SPDM CONTROL BOX
NIDEC ASI S.P.A. – SPDM CONTROL BOX USER MANUAL
32 IMSPDCB2EN
Jumpers, switches and buttons3.1
3.1.1 Jumpers
This section describes the jumper settings. It is recommended to shut down the power of the card before configuration of the jumpers.
The following figure shows the layout of the jumpers on the component side.
Figure 3-2: Jumpers layout.
