28
s
3 Attach the lens.
Keeping the mounting mark on the lens aligned with the
mounting mark on the camera body, position the lens in the
camera’s bayonet mount (q).
Being careful not to press the
lens-release button, rotate the lens counter-clockwise until it
clicks into place (w).
A Detaching the Lens
Be sure the camera is off when removing or
exchanging lenses.
To remove the lens, press and
hold the lens release button (q) while turning
the lens clockwise (w).
After removing the lens,
replace the lens caps and camera body cap.
A Lens Focus Mode
If the lens is equipped with a focus mode
switch, select autofocus mode (A, M/A, or A/M).
D CPU Lenses with Aperture Rings
In the case of CPU lenses equipped with an aperture ring (0 403), lock
aperture at the minimum setting (highest f-number).
A Image Area
The DX format image area is automatically
selected when a DX lens is attached (0 86).
Image area
