VBA10401-R.3623.A
- Ｄ18 ･ -
・
Remove the tape (#797).
・
Take out 2 screws (#653) to remove the inner LCD unit (#B2010).
Black
：
Fmin
Brown
：
Fmin
Soldering bridges
Green
：
SQ
Orange
：
SQ
Yellow
：
SQ
Blue:Mg
Red:Mg
Soldering bridges
#B2010
#653×2
Front body FPC
：
#1009
Inner LCD unit
Front body FPC
#797
