VBA10401-R.3623.A
- Ａ52 ･ -
(7) TFT view angle adjustment
This is for adjusting the display position of TFT. Make an adjustment only for NTSC. (Unnecessary for
PAL)
(8) CCD-PCB EEPROM ashram up
Copy the EEPROM value of the CCD-PCB into the ash memory of the memory compression PCB (AK
PCB).
The ashram up is necessary when the memory compression PCB (AK PCB) is replaced.
The shooting image-related adjustment values are stored in EEPROM of the CCD-PCB, but the camera
does not directly access the CCD-PCB EEPROM. It does read out the value, which is stored in the ash
memory of the AK PCB of the memory compression PCB, and go to RAM to operate. Therefore, to reect
the adjustment value, it is necessary to copy the stored value of the CCD-PCB EEPROM into the ash
memory.
※ When the shooting image adjustments of each (1) - (3) are completed, the software automatically
performs the ashram-up.
(9) TFT PCB EEPROM ashram up
Copy the EEPROM value of the TFT PCB, as performed in the above CCD-PCB, into the ash memory.
It is necessary to ashram up when the TFT PCB is replaced.
※ When the TFT view angle adjustment is completed, the software automatically performs the
ashram-up.
(10) Reading of RISC version
Display the RISC rmware version.
