Shooting Image Adjustment
1. Summary
When D70 shooting image-related, TFT display-related and listed parts on Page A36 are replaced, be sure to
make an adjustment by the shooting image adjustment software for D70 (J65048). The details of its function
and how to use this software are as follows:
2. Adjustment software function
(1) "Sensitivity" adjustment
(2) Gr/Gb compensation adjustment (R/B lter)
(3) "Sensitivity ratio" adjustment
(4) CCD black point defect compensation
(5) CCD white point defect compensation
(6) "Sensitivity" and "Sensitivity ratio" reference values calculation
(7) "TFT view angle" adjustment
(8) CCD-PCB EEPROM ashram up
(9) TFT-PCB EEPROM ashram up
(10) Reading of RISC version
※ When the memory compression PCB is replaced, perform the followings: Flashram up of EEPROM value
of the CCD-PCB, Flashram up of EEPROM value of the TFT-PCB, and Pixel defect (black and white
spots) compensation.
※ When the adjustments from (1) to (3) are made, calculate the sensitivity and sensitivity ratio reference
values of (6) by using the reference body in advance, then perform the adjustments.
3. Hardware requirements
OS： Widows98SE，Windows2000，WindowsME，WindowsXP
Japanese or English OS
PC： CPU Pentium Ⅱ or more
Memory 128MB or more
USB1.1
Screen size: 1024×768 pixels or more
4. How to set up
Create any directory in the harddisc of PC, and copy the following les.
・D2HIMG.exe・・・・・・・・ Application le
・STD.DAT・・・・・・・・・ Standard le
・NkdPTP.dll・・・・・・・・・USB-communication application extension le for WinXP
・NkdPTPDi.dll・・・・・・・・USB-communication application extension le for Win98SE,Win2K，
WinME
※ Be sure to copy the above les in the same directory.
5. Install USB driver
When this software is used, connect the camera via USB connection and install the USB driver.
As for Windows2000, WindowsME, Windows98SE, install the USB driver by using NikonCapture.
However, it is NOT necessary to install it in WindowsXP because the OS incorporates the driver.
*Before connecting the camera and PC, set USB to "PTP". (Setup menu → USB → PTP)
*
