III Additional Functions
3 Restricting Rotation of Revolving Nosepiece
- 33 -
III
3 Restricting Rotation of Revolving Nosepiece
You can restrict the rotation of the revolving nosepiece with the OBJECTIVE key, so that the revolving nosepiece
will not turn from the set z-axis position and upward. The upper limit setting is effective for all the addresses of the
revolving nosepiece.
(1) Set Rotation Restriction
1
Press the MODE key, and the SETTING MENU screen will
appear on the LCD.
Select “More” using the
S key or the T key and then
press the [

] key.
ＳＥＴＴＩＮＧ ＭＥＮＵ
Ｏｂｊｅｃｔｉｖｅ
Ｃｏｎｄｅｎｓｅｒ
Ｆｉｌｔｅｒ
Ｅｘｃｉｔｅｒ
Ｂａｒｒｉｅｒ
Ｃｏｍｂｉｎａｔｉｏｎ（Ｏｂｊ．＞Ｃｏｎｄｅｎｓｅｒ）
Ｃｏｍｂｉｎａｔｉｏｎ（Ｆｉｌｔｅｒ＞ＥＸ／ＢＡ）
Ｍｏｒｅ
2
Select “Rotation Stopper” using the S key or the T key
and then press the [

] key.
ＭＯＲＥ
Ｒｏｔａｔｉｏｎ Ｓｔｏｐｐｅｒ
Ｆｏｃｕｓ
Ｏｔｈｅｒ Ｕｎｉｔ
Ｒｅｍｏｔｅ Ｃｏｎｔｒｏｌ Ｐａｄ
Ｓｈｕｔｔｅｒ Ｋｅｙ
Ｆｏｏｔ Ｓｗｉｔｃｈ
Ｃｏｍｍｕｎｉｃａｔｉｏｎ Ｄｅｌｉｍｉｔｅｒ
3
Move the z-axis position to the position to restrict the
revolving nosepiece rotation (the position at which you
want the revolving nosepiece to stop turning).
4
Move the cursor to “ON” using the W key or the X key
and then press the [

] key.
ＲＯＴＡＴＩＯＮ ＳＴＯＰＰＥＲ
Ｃｕｒｒｅｎｔ ｓｅｔｔｉｎｇ：ＯＦＦ
ＯＮ ＯＦＦ
5
A confirmation message appears.
Press the [

] key.
To cancel, move the cursor to “NO” using the
W key or the
X key and then press the [

] key.
ＲＯＴＡＴＩＯＮ ＳＴＯＰＰＥＲ
Ｃｕｒｒｅｎｔ ｓｅｔｔｉｎｇ：ＯＮ
ＯＮ ＯＦＦ
Ｒｏｔａｔｉｏｎ ｓｔｏｐｐｅｒ ＯＮ ？
Ｙｅｓ Ｎｏ
6
When the setting is accepted, the “Complete!” message
appears and remains displayed for about one second.
ＲＯＴＡＴＩＯＮ ＳＴＯＰＰＥＲ
Ｃｕｒｒｅｎｔ ｓｅｔｔｉｎｇ：ＯＮ
ＯＮ ＯＦＦ
Ｃｏｍｐｌｅｔｅ！
7
Press the MODE key to end the setting and to return to the
OPERATION screen.
