VI Maintenance Menu
2 Testing Electrical Component Operations
- 58 -
2 Testing Electrical Component Operations
Test the operations of the electrical components connected to the HUB controller.
There are two test modes.
All-test mode: Test all the electrical components connected.
Individual test mode: Select a component and test the component.
(1) All-Test Mode
1
Turn on the power to the HUB controller while holding
down the MODE key.
After the MAINTENANCE MENU screen appears, press
the MODE key.
Select “TEST 1” using the
S key or the T key and
release the [

] key.
ＭＡＩＮＴＥＮＡＮＣＥ ＭＥＮＵ
１．Ｖｅｒｓｉｏｎ
２．
ＴＥＳＴ１
３．ＴＥＳＴ２
４．ＰＡＤ Ｄａｔａ
５．ＨＵＢ Ｄａｔａ
６．Ｃｏｎｔｒｏｌ Ｄａｔａ
ａ．Ａｌｌ Ｃｏｎｔｒｏｌ Ｄａｔａ
ｂ．Ｒｅｖｏｉｖｉｎｇ Ｎｏｓｅｐｉｅｃｅ
ｃ．Ｃｏｎｄｅｎｓｅｒ Ｃａｓｓｅｔｔｅ
ｄ．Ｌｉｇｈｔ Ｐａｔｈ
ｅ．Ｆｉｌｔｅｒ Ｂｌｏｃｋ
ｆ．Ｅｘｃｉｔｅｒ Ｆｉｌｔｅｒ
ｇ．Ｂａｒｒｉｅｒ Ｆｉｌｔｅｒ
ｈ．ＡＵＸ Ｆｉｌｔｅｒ
2
On the TEST 1 screen, the arrow “→” is pointed at
“All-Test.” Press the [

] key.
“
→” moves to “OBJECTIVE” and the test will begin.
ＴＥＳＴ１ １／５
→ ＡＬＬ ＴＥＳＴ
ＯＢＪＥＣＴＩＶＥ
１ ［ ］
２ ［ ］
３ ［ ］
４ ［ ］
５ ［ ］
６ ［ ］
・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・
Ｓｅｌｅｃｔ ｉｔｅｍ
ａｎｄ ｐｒｅｓｓ ｅｎｔｅｒ ｔｏ ｓｔａｒｔ．
3
The test results are indicated in [ ] as “OK” or “NG.”
ＴＥＳＴ１ １／５
ＡＬＬ ＴＥＳＴ
→ ＯＢＪＥＣＴＩＶＥ
１ ［ＯＫ ］
２ ［ ］
３ ［ ］
４ ［ ］
５ ［ ］
６ ［ ］
・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・
Ｒｕｎｎｉｎｇ ＡＬＬ ＴＥＳＴ．．．
Ｐｒｅｓｓ ｅｎｔｅｒ ｔｏ ｐａｕｓｅ．
