Service Manual: SC750, SC800, SC 750 ST, SC800 ST
Form Number 56043150 Page 10
Indicator Lights
All indicator lights illuminate for 2 seconds when the key is rst turned on.
Indicator Name Descripon
Soluon Flow Indicators • No ow = None lit
• Low ow = Boom one lit
• Medium ow = Boom two lit
• High ow = All lit
Scrub Pressure Indicators • Regular Scrub Pressure = Boom one
lit
• Extreme Scrub Pressure = Both lit
Vacuum Indicator • Vacuum on = On
• Vacuum o = O
• Time Delay before shut o = Flashing
Detergent Indicator • Detergent on = On
• Detergent o = O
Burst of Power Indicator • Switch disabled = O
• Switch enabled = On - Green
• Burst of Power = Flashing - Yellow
