OCM Pro CF
OCM Pro CF - Rev. 09 as of 07.06.2016 page 129
This is the folder where the backup file is saved. Carry out the saving process
by calling it up under >I/0 – Memory Card – Save backup<.
The name of the saved file is always >Q_H_V_T.TXT<. It contains the internal
memory values on level, velocity, flow and temperature.
The file >DIAG.TXT< contains all messages including error messages which
might have been occurred during measurement operation. These might be start
and end of Internet communication, modem restart, CPU restart after system
reset or after reprogramming.
The respective message is labelled with date and time:
>: received error/message
<: reason of error/message cleared
Execute saving the DIAG by calling up from >I/0 – Memory Card – Save
backup<.
This folder includes all parameter files with a date stamp.
The content of this folder allows to retrace transmitter settings regarding the
measurement place as well as parameter settings which might have been
modified.
The latest modification within the course of a day will be saved.
The file name is: PA TT MM JJ .TXT
(TT = day, MM = month; JJ = year)
The name of the measurement place.
If the name of the measurement place saved on card does not comply with the
name of the measurement place saved in the OCM Pro CF, the unit will prompt
to format the card. The OCM Pro CF will not save any data as long as the card
has not been formatted.
Place.TXT
This is the file where the measurement values are saved. It is going to be saved
using the name of the measurement place set.
PARAMET.TXT
These files are created as soon as parameters are being saved on the memory
card. The file PARAMET.NIV is required in order to upload data to the OCM
Pro. PARAMET.TXT is the print version of PARAMET.NIV as text file (only
parameters modified before are going to be exported).
Important Note
Use memory cards purchased from NIVUS only. Other manufacturer’s cards
may lead to loss of data or measurement failure (permanent transmitter reset).
