10 Parameter Tree
Parameter Menu (PAR) Part 1
PAR
measurement place
name nivus
subdivide geometry no
no 2 3
2 3
channel shape(s)
round pipe x
3r egg
rectangle
U-profile
trapezoid
custom shape
height/width
height/area
2r egg
Q=f(h)
channel geometry 0.5
sludge level 0
Q-min
Qmin 0
Vmin 0
2 only active if "subdivide geometry" = 2
channel shape
bottom
round pipe x
3r egg
rectangle
U-profile
trapezoid
2r egg
Q=f(h)
top
custom shape x
height-width
height-area
channel dimensions
area bottom depending on previously selected profile
prompting for r, h/w, r/h, lower/upper w/h
or h/Q
area top
depending on selection
height-width or height-area table
