OCM Pro CF
page 32 OCM Pro CF - Rev. 09 as of 07.06.2016
The terminal clamps are normally unscrewed on delivery. Nevertheless this must
be checked before connecting the power supply or the signal wires.
Note
While connecting, it is helpful to exert slight pressure on the terminal clamp
screw.
This ensures safe cable connection by opening the clamp.
Important Note
Close the terminal clamp compartment of the wall mount enclosure by using
the accompanying cover and both screws. Closing prevents water or dirt from
leaking in.
Observe to not reverse the cover during installation (steeply bevelled side up).
The specified protection degree cannot be guaranteed if the cover is not in-
stalled correctly.
