OCM Pro CF
page 64 OCM Pro CF - Rev. 09 as of 07.06.2016
Set the start point for the trend graph to be indicated under point 1. The resolu-
tion (scale of the time axis) can be set under point 2. Select here between
10 minutes, 1 hour, 6 hours or 24 hours/grid line. A click on the >Update< button
(point 3 in Fig. 7-54) will refresh the screen by the new measurement data which
have been collected whilst watching.
Note
If the selected start date/time of the trend is the current date/time or if the time
axis range allows to view a greater range than selected by start date/time and
resolution this will cause the screen to indicate older values than selected
additionally.
Log out the on-site unit by using the >Logout< button located on the left-hand
side of the screen as well. This will take you back to the NIVUS homepage.
Note
If no data transmission has been executed for 5 minutes, the OCM Pro CF will
automatically interrupt the connection in order to avoid unnecessary expens-
es.
