1 Sedimentation or soiling
Fig. 9-37 Sensor type 5: internal pressure
Sensor type 6: 2-wire probe
Here the level is measured by using an external 2-wire source such as the type
NivuMaster echo sounder or a pressure probe type HydroBar. Both can be com-
bined with the flow velocity sensor.
Fig. 9-38 Sensor type 3: 2-wire probe
Note
For connection see Fig. 7-12 or Fig. 7-29.
