Nokia RM-497 - Electrical Interface between Baseband and Charger

Electrical Interface Between Baseband and Charger
Introduction
The main battery charger of the LOVIISA PMU (N2201) features an autonomous, yet, fully customizable pulse-
mode charger and switch-mode charger for a single-cell Li-ion polymer battery. The LOVIISA PMU supports
trickle and rapid charge via wall or USB chargers.
RM-497
System Module
