XRS-6 RF cable
The RF cable is used to connect, for example, a module repair jig to
the RF measurement equipment.
SMA to N-Connector approximately 610 mm.
Attenuation for:
GSM850/900: 0.3+-0.1 dB
GSM1800/1900: 0.5+-0.1 dB
Service concepts
POS (Point of Sale) flash concept
Figure 2 POS flash concept
RM-497
Service Devices and Service Concepts
Page 2 – 10 COMPANY CONFIDENTIAL Issue 1
Copyright © 2010 Nokia. All rights reserved.
