Figure 21 Accelerometer troubleshooting probe placement diagram
Baseband manual tuning guide
Certificate restoring
Context
This procedure is performed when the device certificate is corrupted for some reason.
All tunings (RF & Baseband, UI) must be done after performing the certificate restoring procedure.
The procedure for certificate restoring is the following:
•
Flash the phone with the latest available software using FPS-10 and FPS-21.
Note: If the COMBO memory of a phone is replaced, the ENO SW must be flashed first before
performing the "normal" firmware flashing.
•
Execute the certificate restore process in Phoenix.
RM-497
BB Troubleshooting and Manual Tuning Guide
Issue 1 COMPANY CONFIDENTIAL Page 3 – 49
Copyright © 2010 Nokia. All rights reserved.
