Nokia RM-497 User Manual

Table 12 Top Level Power Distribution Table
Supply Voltage Chip # Ref Function
Battery Vbat BCM 59036 N2201 Power
Management
Battery Vbat TPS61061YZFR N2301 LED Backlight
Driver
Battery Vbat TPA2010D1YZFR N2801 IHF Audio
Amplifier
Battery Vbat TS4601EIJ N2000 Headset Audio
Amplifier
Battery Vbat LCD Voltage
Connector
X3600 LCD
Battery Vbat Skyworks 77528 N7500 FEM
BCM59036 HC1 3.0V LIS302DL N6501 Accelerometer
BCM 59036 AUX1 2.8V LCD Voltage
Connector
X3600 LCD
BCM 59036 VIO 1.8V LCD Voltage
Connector
X3600 LCD
BCM 59036 VIO 1.8V HED54XXU11 N6500 Hall Sensor
BCM59036 HC1 3.0V KHN4NX1RA M3440 Vibrator
BCM 59036 VIO 1.8V BTFMMTXRDS3_0B N/A Blue Tooth & FM
Radio
BCM59036 VIOSR 1.8V K5W1G12ACG-
BL60
D3000 Memory
BCM59036 MSLDO1 2.8V Camera Connector ACF Camera
BCM59036
AUXLDO2
1.8V Camera Connector ACF Camera
BCM59036 HC2 3.0V SD card Connector X3560 SD Card
BCM59036 VSIM 1.8/3.0V SIM Card Connector X3540 SIM
Table 13 59036PMU&21351 BB Power Distribution Table
Signal Name Regulator
Type
PMU Pin Status on
reset
Rating (V) Rated (mA) 21351
Function
VX LDO AUXLDO1 OFF 1.8 150 LCD Analog
VAMP1 LDO HCLDO1 OFF 3.2 350 Analog :
Vibra, DDAC
L&R
VAMP2 LDO HCLDO2 OFF 3.2 350 Digital SDIO
VANA1 LDO LVLDO1 ON 1.2 150 Analog:USB,
Dual DAC,
DSI, M&APLL
RM-497
System Module
Page 5 – 28 COMPANY CONFIDENTIAL Issue 1
Copyright © 2010 Nokia. All rights reserved.
