SS-62 Generic flash adapter
base for BB5
• generic base for flash adapters and couplers
• SS-62 equipped with a clip interlock system
• provides standardised interface towards Control Unit
• provides RF connection using galvanic connector or coupler
• multiplexing between USB and FBUS media, controlled by VUSB
SS-71 Domesheet
alignment jig
The domesheet alignment jig will be only supplied for APAC and China
regions only.
The purpose of this tool is to simplify the attachment process of the
domesheet to the keymat PWB. In other regions the complete
assembly (keymat PWB & domesheet is used as a spare part)
ST-40 PA rework stencil
This stencil is to be used together with RJ-93 and covering FEM module.
XCS-4 Modular cable
XCS-4 is a shielded (one specially shielded conductor) modular cable
for flashing and service purposes.
RM-70
Service Tools and Service Concepts Nokia Customer Care
Issue 1 COMPANY CONFIDENTIAL Page 4 –11
Copyright © 2005 Nokia. All rights reserved.
