1 Before installation
3
1.3 Outline of connecting devices
Example: If the scanner is connected to a PC on which the Controller is not installed
Example: If the scanner is connected to a PC on which the Controller is installed
1.4 Installation place
!
!!
! Weight
• LS-600: approx. 16.7 kg
• LS-1100: approx. 17.5 kg
!
!!
! Conditions for installation place
• Requires strength to support the scanner weight.
• Must be level, and not cause vibration. Vibration should be 3 m/s
2
(0.3 G) or less in each direction at the installation
place.
!
!!
! Conditions for power supply
• Confirm that a power supply with ground resistance of 100Ω or less is available.
1.5 Required items
The following items are required.
USB
Scanner
PC (prepared by users)
G087688
USB
LAN
Scanner
Printer
PC on which the Controller is
installed
G088478
