1 Before installation
4
Confirm that the following items are prepared before you start working.
1.6 Removing packing angle brackets and antirust material
The removed packing angle brackets are not reused. However, they are necessary when the product is sent back because of
failure, etc. Be sure to keep them.
1. Remove the packing angle brackets.
(1) Open the front cover and side cover (left).
Required item Required item
PC
(See the Specifications
for details about the
recommended
specification of the PC)
Grounding adapter
(as necessary)
Philips blade screwdriver
(large)
Power cord
(Power code is supplied
in Japan and North
America. For other
countries, prepare a
power code that meets the
following specifications.)
• Input voltage: 250 V
(220 V-240 V) and
rating capacity of 6
A or more
• Plug type:
acceptable one in
each country
• Cable type: one of
the following type
and 19 AWG (0.75
mm
2
) or more
• 20195
• SJT
• SVT
• UL/CSA/VDE-
approved products
Front cover
Side cover
G087613
