Installation Installation Checklist
28 NFS-640 Installation Manual P/N 51332:B1 12/01/2003
3.2 Installation Checklist
Table 2 provides an installation checklist for installing, wiring, and testing the NFS-640 system. It
has references to installation information included in manuals listed in Section 1.2 “Supplemental
Documentation”.
Table 2 Installation Checklist
Seq Task Refer to
1. Mount the cabinet backbox to the wall. Section 3.3 “Mounting a Cabinet”
2. Install all required chassis in cabinet. Section 3.5 “Installing the Control Panel”
3. Install control panel onto chassis. Section 3.5.1 “Control Panel Circuit Board & Keypad/
Display Unit”
4. Optional: Install auxiliary power supply and/or
external battery charger
Auxiliary power manuals
5. Calculate the proper battery rating. Appendix A “Power Supply Calculations”
6. Connect AC wiring, place batteries into backbox
without connecting them, and run cable to optional
power supplies, DC power outputs, NACs, and
relays.
CAUTION: Do not apply AC or DC power at this
time.
Section 13 “Mounting Single-space Blank Plate with
Optional Module Connecting the Power Cables”
7. Set switches for backup alarm (SW6-SW9). Section 3.5.14 “Backup-Alarm Switches”
8. Optional: Install and wire Auxiliary Relay Module
(ARM-4).
Section 3.8 “Auxiliary Relay Module (ARM-4): Product-
Specific Details”
9. Optional: Install Panel Circuit Modules (ICM-4RK,
CRM-4RK, VCM-4RK, DCM-4RK) and Voice Alarm
System components (AMG-1, FFT-7, Audio
Amplifiers)
Section 3.7 “Installing Panel Circuit Modules”, and
Voice Alarm System Manual
10. Optional: Install output devices such as a printer, or
CRT terminal.
Section 3.9 “Installing Remote Printers and/or CRT”
11. Optional: Install NCA or NCS. NCA Manual or NCS Manual
12. Secure any unused mounting holes in control panel
circuit board.
Figure 8
13. Wire the Signaling Line Circuits. Section 3.10 “Wiring a Signaling Line Circuit (SLC)”
14. Connect wire shielding as instructed. SLC Wiring Manual
15. Apply AC power to the control panel by placing the external circuit breaker to the ON position.
Do NOT connect batteries.
16. Check AC power. Table 4 in Section 13 “Mounting Single-space Blank
Plate with Optional Module Connecting the Power
Cables”
17. Connect the batteries using interconnect cable, P/N 75560 and 75561.
18. Install the CAB-4 series door. CAB-3/CAB-4 Series
Cabinet Installation Document
19. Program the control panel. NFS-640 Programming Manual.
20. Field test the system. Section 5 “Testing the System”
