Installation Installing the Control Panel
36 NFS-640 Installation Manual P/N 51332:B1 12/01/2003
Figure 11 Inserting a Module into a Chassis
Figure 12
Location of Stand-offs on Module Chassis
Note: See the BMP-1 Product Installation Drawing for details if considering mounting the module
behind blank module plate in a dress plate or annunciator backbox. This dress plate is suitable for
modules that do not need to be visible or accessible when the door is closed.
nfs640-mnticm.cdr
Shown with CHS-M2
Module
Screw
Slots
Shown with CHS-4N
CHS-4studpos.cdr
Install stand-offs on these
two (2) studs in any one of
four positions along chassis.
Chassis CHS-4N
