Revision 1.03
3-4 ChannelMaster TX7 Transmitter
System:
Video Presence: .................................. Remote Standby/Test Generator Selectable
Test Generator(Dynamic):................... SMPTE CB(NTSC)/100% CB(PAL)
16 Character ID(Match SDT Service name
1KHz Tone/Pulse
ASI:...................................................... Rate converted from 0mpbs-Max modulation
Rate
PCR Retime stamp
Encryption:........................................... Optional AES Block Cypher, supporting key
size of 128 and 256bits (FIPS PUB 197)
Mic Phantom Power: ........................... 10V Phantom Power output on right XLR conn.
pins 2, 3.
Remote Control:
Electrical Interface: .............................. RS232/RS485(2 wire)
Power Requirements:
Input range: ........................................ AC: 90 to 132VAC, 60 Hz
AC: 180 to 264VAC, 50 Hz
DC: +11 to +32V
Power consumption:........................... 80 W typical (12 watt version)
Environmental Specifications:
Temperature range:
Operating:........................................... –30° to +60°C
Storage: ............................................. –40° to +80°C
Humidity: ................................................. 0 to 95% non-condensing
Altitude:
Operating:........................................... 20,000ft (6,000 m)
Storage:.............................................. 50,000ft (15,000 m)
