Revision 1.03
Specifications and Frequency Plans 3-5
Physical Characteristics:
Size (Low Pwr Unit): ............................... 4.89" (12.42 cm) x 7.5" (19.05 cm) x
12.0"(30.48 cm)
Size (Hi Pwr Unit): ................................... 5.2" (13.21 cm) x 7.5" (19.05 cm) x
12.0"(30.48 cm)
Weight:
Single-Band, No Shroud (typ.): .......... 15.00 lbs (6.80 kg)
Dual-Band, No Shroud (typ.):............. 16.00 lbs (7.26 kg)
Single-Band, Shrouded (typ.):............ 15.50 lbs (7.03 kg)
Dual-Band, Shrouded (typ.): .............. 16.50 lbs (7.48 kg)
Tri-Band, Shrouded (typ.):.................. 18.50 lbs (8.39 kg)
Control:
Menu Selection and Entry:....................... Combination Rotary knob/push button
Operating Mode Buttons:......................... Membrane Switches
Connectors:
Video/SDI / DVB-ASI/70MHz:.................. Type BNC-F
Firewire Serial Digital Video Input:........... IEEE1394 Connector (Optional)
Audio:....................................................... Multi Pin “MS” Style (XLR break out provided)
XLR Jacks (Optional)
RF Output: ............................................... Type “N” female
Remote Control:....................................... 9 Pin D, Female
Power:...................................................... Multi Pin “MS” Style
Case:
Ruggedized to withstand rough handling in the field with handles that protect controls
from damage. Case is weather-resistant and all connectors are weatherproofed.
