TECHNICAL OWNER MANUAL
Table of contents
1. NuVinci Optimized products 3
1.1 Nfinity 330
TM
and Nfinity 380
TM
Series Drivetrains 3
1.2 The NuVinci Optimized CVP 3
2. Nfinity operation & care 4
2.1 Shifting Nfinity Systems While Riding 4
2.2 Shifting Nfinity Systems While Stopped 4
2.3 Adjusting Cable Slack 5
2.4 Disconnecting the Rear Wheel 6
2.5 Fitting the Rear Wheel 7
2.6 Cleaning & Lubrication 8
2.7 Wear Parts & Repair Work 8
3. Nfinity assembly of components 9
3.1 Wheelbuilding 9
3.2 Installing the Sprocket 10
3.3 Nfinity Hub Interface
Compatibility & Orientation 11
3.4 Installing the Nfinity Hub Interface 12
3.5 Installing the Shifter 13
3.6 Installing Shift Cable Housing 14
3.7 Installing Shift Cables and Hardware 15
4. Nfinity service instructions 16
4.1 Replacing Shifter Cables 16
4.2 Resetting CVP to Full Overdrive 18
4.3 Servicing or Replacing Freewheel 20
4.4 Removing Brake Configurations 21
4.5 Installing Brake Configurations 22
5. Nfinity technical data 23
5.1 CVP Specifications 23
5.2 Approved Gearing 24
5.3 Exploded View 25
5.4 CVP & Nfinity Shifter Dimensions 26
6. Intellectual property notice 27
7. Warranty 28
European Support and Service 29
North American Office 29
