TECHNICAL OWNER MANUAL
5. Nfinity technical data
NFINITY TECHNICAL DATA
5.1 CVP Specifications
Hub N330
Hub Colors Silver or black
CVP weight 2.450 grams
Speed ratio Infinitely variable within ratio range
Ratio range 330% nominal, 0.5 underdrive to 1.65 overdrive
Controller C3
Other compatible controller C8, C8s and N360 shifter (all MY)
Shifting Variable twist grip, ¾ turn
Hub Interface Nfinity Hub Interface 330
Other compatible HI‘s –
Spoke configurations 32 or 36 hole
Brake configurations Disc, rim, or roller
CVP weight 2450 grams
Drop-Out Width 135mm, horizontal or vertical
Axle Length 183mm
Axle Threads M10 x 1
Chainline 49.0 ± 0.5mm
Beltline (Gates) 45.5 ± 0.5 mm
Beltline (Conti-Tech) 46.2 ± 0.5 mm
Sprocket sizes 16-22 tooth (chain)
20-28 tooth (belt)
Sprocket type Standard 9-spline, flat on one side
Sprocket ratio definition Front sprocket teeth / Rear sprocket teeth
Sprocket ratio minimum (Pedal bikes) 1.8 (Table in section 5.2)
Sprocket ratio minimum (Front motor e-Bikes) 1.8 (Table in section 5.2)
Sprocket ratio minimum (Mid motor e-Bikes) 2.1 (Table in section 5.2)
Sprocket ratio minimum (Bosch GEN2 eBikes) 0.84 (Table in section 5.2)
Spoke flange diameter 125.0 mm
Center to left spoke flange 26.0 mm
Center to right spoke flange 26.0 mm
Nfinity 330
Hub N380
Hub Colors Silver or black
CVP weight 2.450 grams
Speed ratio Infinitely variable within ratio range
Ratio Range 380% nominal, 0.5 underdrive to 1.9 overdrive
Controller C8
Other compatible controller C3, C8s and N360 shifter (all MY)
Shifting Variable twist grip, ¾ turn
Hub Interface Nfinity Hub Interface 380
Other compatible HI‘s –
Spoke Configurations 32 or 36 hole
Brake Configurations Disc, rim, or roller
CVP weight 2450 grams
Drop-Out Width 135mm, horizontal or vertical
Axle Length 183mm
Axle Threads M10 x 1
Chainline 49.0 ± 0.5mm
Beltline (Gates) 45.5 ± 0.5 mm
Beltline (Conti-Tech) 46.2 ± 0.5 mm
Sprocket Sizes 16-20 tooth (chain)
20-28 Tooth (belt)
Sprocket type Standard 9-spline, flat on one side
Sprocket ratio definition Front sprocket teeth / Rear sprocket teeth
Sprocket ratio minimum (Pedal bikes) 1.8 (Table in section 5.2)
Sprocket ratio minimum (Front motor e-Bikes) 1.8 (Table in section 5.2)
Sprocket ratio minimum (Mid motor e-Bikes) 2.0 (Table in section 5.2)
Sprocket ratio minimum (Bosch GEN2 eBikes) 0.8 (Table in section 5.2)
Spoke flange diameter 125.0 mm
Center to left spoke flange 26.0 mm
Center to right spoke flange 26.0 mm
Nfinity 380
Nfinity 330 systems
are compatible with
mid-motor eBike
systems rated at 250W
or less. See section 5.2 for
approved gearing tables.
Nfinity 380 systems are
compatible with mid-motor
eBike systems rated at 350W
or less. See section 5.2 for
approved gearing tables.
!
