NVision NV6000 Series User Manual

UG8000-00 November 2002
Page 1-11
Figure 1-4. NV6128 Front
REDUNDANT
POWER SUPPLY 1
REDUNDANT
POWER SUPPLY 2
MAIN
POWER SUPPLY 1
MAIN
POWER SUPPLY 2
FAN
128X32 CROSSPOINT OUTPUTS 1-32
128X32 CROSSPOINT OUTPUTS 33-64
128X32 CROSSPOINT OUTPUTS 65-96
128X32 CROSSPOINT OUTPUTS 97-128
INPUTS 1-8 INPUTS 9-16 INPUTS 17-24 INPUTS 25-32 INPUTS 33-40 INPUTS 41-48 INPUTS 49-56 INPUTS 57-64 INPUTS 65-72 INPUTS 73-80 INPUTS 81-88 INPUTS 89-96 INPUTS 97-104 INPUTS 105-112 INPUTS 113-120 INPUTS 121-128
OUTPUTS 1-8 OUTPUTS 9-16 OUTPUTS 17-24 OUTPUTS 25-32 OUTPUTS 33-40 OUTPUTS 41-48 OUTPUTS 49-56 OUTPUTS 57-64 OUTPUTS 65-72 OUTPUTS 73-80 OUTPUTS 81-88 OUTPUTS 89-96 OUTPUTS 97-104 OUTPUTS 105-112 OUTPUTS 113-120 OUTPUTS 121-128 OUTPUT MONITOR - OPTIONAL
CONTROLLER - SECONDARY - OPTIONAL
CONTROLLER - PRIMARY
FAN
1
2
3
4 4
5
6
7 7
88
MT6000-3
